JIS Standard

Chemical Composition ( Mass % )
Alloy CU SI MG ZN FE MN CR NI SN PB TI AL
ADC1 1.0 max 11.0 to 13.0 0.3 max 0.5 max 1.3 max 0.3 max 0.5 max 0.1 max 0.20 max 0.30 max Remainder
ADC3 0.6 MAX 9.0 to 11.0 0.4 to 0.6 0.5 max 1.3 max 0.3 max 0.5 max 0.1 max 0.15 max 0.30 max Remainder
ADC5 1.2 max 0.3 max 4.0 to 8.5 0.1 max 1.8 max 0.3 max 0.1 max 0.1 max 0.1 max 0.20 max Remainder
ADC6 1.0 max 1.0 max 2.5 to 4.0 0.4 max 0.8 max 0.4 to 0.6 0.1 max 0.1 max 0.1 max 0.20 max Remainder
ADC10 2.0 to 4.0 7.5 to 9.5 0.3 max 1.0 max 1.3 max 0.5 max 0.5 max 0.2 max 0.20 max 0.30 max Remainder
ADC10Z 2.0 to 4.0 7.5 to 9.5 0.3 max 3.0 max 1.3 max 0.5 max 0.5 max 0.2 max 0.20 max 0.30 max Remainder
ADC12 1.5 to 3.5 9.6 to 12.0 0.3 max 1.0 max 1.3 max 0.5 max 0.5 max 0.2 max 0.20 max 0.30 max Remainder
ADC12Z 1.5 to 3.5 9.6 to 12.0 0.3 max 3.0 max 1.3 max 0.5 max 0.5 max 0.2 max 0.20 max 0.30 max Remainder
ADC14 4.0 to 5.0 16.0 to 18.0 0.45 to 0.65 0.5 max 1.3 max 0.5 max 0.3 max 0.3 max 0.20 max 0.30 max Remainder
AC4B 2.0 to 4.0 7.0 to 10.0 0.5 max 1.0 max 0.8 max 0.5 max 0.20 max 0.35 max 0.10 max 0.20 max 0.20 max Remainder
AC2B 2.0 to 4.0 5.0 to 7.0 0.5 max 1.0 max 1.8 max 0.5 max 0.20 max 0.35 max 0.10 max 0.20 max 0.20 max Remainder
AlSi9Mg 0.03 max 9.0 to 10.0 0.30 to 0.45 0.07 max 0.15 max 0.10 max 0.15 max Remainder
AlSi10Mg 0.08 max 9.0 to 11.0 0.25 to 0.45 0.10 max 0.45 max 0.45 max 0.05 max 0.05 max 0.05 max 0.15 max Remainder
AlSi9Cu1Mg 0.8 to 1.3 8.3 to 9.7 0.30 to 0.65 0.80 max 0.7 max 0.15 to 0.55 0.25 max 0.10 max 0.10 max 0.10 to 0.18 Remainder
AlSi9Cu3(Fe) 2.0 to 4.0 8.0 to 11.0 0.05 to 0.55 3.0 max 1.3 max 0.55 max 0.15 max 0.55 max 0.25 max 0.35 max 0.25 max Remainder
AlSi12Cu1(Fe) 0.7 to 1.2 10.5 to 13.5 0.35 max 0.55 max 1.3 max 0.55 max 0.10 max 0.30 max 0.10 max 0.20 max 0.20 max Remainder
AS9 2.2 to 3.5 9.0 to 10.0 0.40 max 0.1 max 0.3 max 0.15 to 0.25 0.05 max 0.40 max 0.03 max 0.10 max 0.01 max Remainder
A413 0.3 to 0.5 11.0 to 12.0 0.10 max 0.1 max 0.8 to 1.3 0.3 max 0.01 max 0.01 max 0.005 max 0.01 max Remainder
T-1088 0.1 max 11.5 to 12.0 0.10 max 0.1 max 0.7 to 0.8 0.25 to 0.35 0.01 max 0.01 max 0.01 max 0.01 max Remainder
HSIH 2.5 to 3.0 6.0 to 7.0 0.15 to 0.30 0.4 max 0.6 max 0.2 max 0.01 max 0.01 max 0.01 max 0.02 max Remainder
